Railway Certified Computers

Assured Systems supply a wide range of Railway Certified Computers fully configured with your choice of processor, memory, storage, peripheral cards and operating system.

Embedded Computing

RPC/RSL81I20-A154E

Syslogic RPC/RSL81I20-A154E RPC Compact 81 Ruggedized Computer for In-Vehicle, Rollingstock & Automotive Applications
  • ISO 20653

Embedded OEM M-81

Syslogic Intel Atom/Celeron/Pentium Embedded Computer OEM M-81 with Digital IO and ECC Memory
  • CPU: Intel Atom/Celeron/Pentium
  • Memory: Up to 8GB
  • Max Temp Range: -40°C to +70°C
  • Power Input: 9 to 30 VDC
  • Certifications: CE/FCC, UL, EN 60068

Embedded OEM S-81

Syslogic Intel Atom/Celeron/Pentium Embedded Computer OEM S-81 with LAN, Serial & USB Options
  • CPU: Intel Atom/Celeron/Pentium
  • Memory: Up to 8GB
  • Max Temp Range: -40°C to +70°C
  • Power Input: 9 to 30VDC
  • Certifications: CE/FCC, UL, EN 60068

Rugged RPC RML A3 (E2)

Syslogic NVIDIA Jetson AGX Xavier Rugged RPC RML A3 (E2) 8x GMSL2 Camera Inputs & Wireless Options
  • CPU: NVIDIA Jetson AGX Xavier
  • Memory: Up to 32GB
  • Max Temp Range: -25°C to +60°C
  • Power Input: 9 to 45VDC
  • Certifications: CE/FCC, E-Mark, ISO 15003

Syslogic AI Railway RML A4NX

Syslogic AI Railway RML A4NX Computer Vision Edge Unit with NVIDIA Jetson Orin NX
  • CPU: NVIDIA Jetson Orin NX
  • Memory: Up to 16GB
  • Max Temp Range: –25°C to +65°C
  • Power Input: 16.8 to 137.5 VDC
  • Certifications: CE/FCC, EN 50155, EN 45545

AI Railway Computer RS A2

Syslogic AI Railway Computer RS A2 EN50155 NVIDIA Jetson TX2i for AI computing at the edge.
  • CPU: NVIDIA Jetson TX2
  • Memory: Up to 8GB
  • Max Temp Range: –40°C to +70°C
  • Power Input: 16.8 to 137.5VDC
  • Certifications: CE/FCC, E-Mark, EN 50155

IPC/RMA2NH20-E202S

Syslogic IPC/RMA2NH20-E202S COMPACT RM A2N NVIDIA Jetson TX2 NX AI Vehicle Computer
  • CPU: NVIDIA Jetson TX2 NX
  • Memory: Up to 4GB
  • Max Temp Range: –25°C to +65°C
  • Power Input: 9 to 45 VDC
  • Certifications: CE/FCC, E-Mark

IPC/RSA2NH20-E102S

Syslogic IPC/RSA2NH20-E102S COMPACT RS A2N NVIDIA Jetson TX2 NX AI Vehicle Computer
  • CPU: NVIDIA Jetson TX2 NX
  • Memory: Up to 4GB
  • Max Temp Range: –25°C ~ +70°C
  • Power Input: 9 to 35 VDC
  • Certifications: CE/FCC, E-Mark

NRU-52S+-JON8

Neousys NRU-52S+-JON8 NVIDIA Jetson Orin NX Edge AI Computer for Intelligent Video Analytics with 8GB Memory

NRU-52S-NX16

Neousys NRU-52S-NX16 NVIDIA Jetson Xavier NX Edge AI Computer for Intelligent Video Analytics with 16GB Memory

NRU-52S-NX8

Neousys NRU-52S-NX8 NVIDIA Jetson Xavier NX Edge AI Computer for Intelligent Video Analytics with 8GB Memory

NRU-52S+-JON16

Neousys NRU-52S+-JON16 NVIDIA Jetson Orin NX Edge AI Computer for Intelligent Video Analytics with 16GB Memory
Showing: 1-12 of 79

Our range of Railway Certified Computers are for use on-board rolling stock. Fanless and solid state, means the systems can cope with the high vibration and shock environments they are subjected to whilst moving. Features popular with railway computers are shock resistance and multiple analogue or digital I/O to receive monitoring and surveillance signals from cameras.

Railway Certified Computers – Further Information

EN 50155 – An international standard required for all electrical equipment used on rolling stock for rail applications, which involves systems standing up to wide temperatures, shock and vibration, a wide range of voltage to power the systems, electromagnetic parameters and evidence of tested performance and reliability.

Any EN50155 system is suitable for the sustained pressures of a rail environment.

EN 50121 – is specific to the electromagnetic compatibility of an electrical device within rolling stack. The system has to be EN50121 compliant, before EN 50155 compliance can be achieved.

The standard restricts electromagnetic interference levels that are emitted to the outside world and with in the train vehicle itself. It measures any potential risk to apparatus used in signalling and telecommunications, as well as fixed power supply installations.

EN 45545 – This standard represents fire standards on railway applications with requirements for the behaviour of materials and components.

EN 61373 – This standard is composite to the EN50155 for railway applications. The EN 61373 is concerned with shock and vibration, testing any electronic device over differing axis and timescales up to 5g.
