M9020

7″ Windows Rugged Tablet Computer with Qwerty Keyboard

End of Life

  • Brand: Winmate
  • Intel Atom N2600 1.6GHz CPU
  • QWERTY Keyboard
  • IP67 for total protection
  • Wide range operating temperature (-20℃ to 60℃)
  • Size: 229.75mm (W) x 183mm (H) x 54mm (D)

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

-
+

Details

The M9020 is a mobile rugged tablet PC from Winmate with a QWERTY keyboard and 5 programmable function keys. The 7" screen has a brightness of 900 NITS with a resolution of 1024 x 600 and the touch technology is 4W Resistive Touch (GFG). The tablet uses the Intel Atom N2600 1.6GHz processor and has a storage capacity of 64GB. Expansion is possible through a Micro SD card slot (up to 32GB) and I/O is via 4 x USB 2.0, 1 x VGA and 4 x RS-232 COM.

This tablet is a really tough unit with multiple chunky comfort grips adding drop protection and there is an equally rugged optional vehicle dock. It's highly protected from liquid and dust ingress up to IP67 and has a wide operating temperature of between -20℃ to 60℃. Wireless communication is via 802.11 a/b/g/n WiFi Card (Cisco Compatible Extensions (CCXv4)) Support Infrastructure and ad hoc (Client Mode) and Class 2 Bluetooth 4.0. A Neo-6 GPS module is built-in and 3G/LTE is optional.

Ordering Info

  • M9020 – 7″ Windows Rugged Tablet Computer with Qwerty Keyboard
  • Please ask our sales team for information on optional vehicle docking station

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  • 7″ ,1024 x 600 resolution with Intel Atom N2600 1.6GHz processor
  • QWERTY Keyboard and 5 programmable FN Keys
  • Superior power management, Li-ion, 7.4V-3100 mAh (hot-swappable)
  • Innovative form factor with multiple comfort grips and custom vehicle dock
  • IP67 for total protection against dust and water
  • Wide range operating temperature (-20℃ to 60℃)
  • CMOS 2D barcode scanner(Reads 1D and 2D barcodes omni- directionally)
  • UHF RFID(By Request)
  • Advance wireless communication
  • C1D2(By Request)

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

Winmate: Warranty and Service Information

We offer a comprehensive 2 year warranty on all Winmate products sold and distributed within the EMEA when purchased directly from Assured Systems. We are proud to be an official Winmate partner and can distribute products with secure and certified delivery directly from our UK centre.
