PM2155-WH25L2

21.5″ Widescreen Panel Mount Touch Monitor Wide Viewing Angle (1920×1080)

PM2155-WH25L2

  • Brand: Winsonic
  • 21.5 inch LED backlit screen
  • Wide viewing angle 178° / 178°
  • 250 NITS brightness
  • Resistive, Capacitive, SAW or Infrared touch options
  • Variety of video input options
  • Size: 603mm (W) x 392mm (H) x 69mm (D)
-
+

Details

The PM2155-WH25L2 from manufacturer Winsonic is a 21.5" front panel mount LCD widescreen touch monitor. The 21.5 inch screen has a resolution of 1920 x 1080, a brightness of 250NITS and a wide viewing angle of 178° / 178°.

The modularized mechanical design provides flexible product configuration and easy maintenance. The product is available with VGA connector or can be configured with a variety of video inputs, Resistive, Capacitive, SAW or Infrared touch options, networking, enhanced panel features and sensors.

Ordering Info

  • PM2155-WH25L2 – 21.5″ Panel Mount touch display with 1920 x 1080 resolution, LED backlight to 250 nits brightness, VGA input, wide view angle

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  • Viewable Image Size: 21.5″
  • Resolution: 1920×1080
  • Ratio: 16:9
  • Brightness: 250cd/m
  • Contrast: 3000:1
  • Viewing Angle: H. 178° (- 89° ~ + 89°) , V. 178° (- 89° ~ + 89°)
  • Bezel: Powder Coated Steel
  • Backlight: LED
  • Video Inputs: VGA
  • Touchscreen: Resistive, Capacitive, SAW or Infrared touch options
  • Power: Internal power supply with universal / Auto-Sensing, AC90 to 260V, 50/60 Hz
Screen Size 21" to 30", 21.5"
Touch Technology Infrared, Projected Capactive, Resistive
Brightness 250nit, Standard

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

Winsonic: Warranty and Service Information

We offer a comprehensive 2 year warranty on all Winsonic products sold and distributed within the EMEA when purchased directly from Assured Systems. We are proud to be an official Winsonic partner and can distribute products with secure and certified delivery directly from our UK centre.
