OH55F

Samsung OH55F 55″ High Bright Outdoor Display 24/7 Usage 2500nit

OH55F

  • Brand: Samsung
  • IP56 dust and liquid protection
  • IK10 rated vandalism protection
  • Sunlight readable anti-reflective screen 2500 NITS
  • Built-in media player
  • Bezel Size: 24.9mm
  • Size: 1260.6 mm (H) x 731.4mm (W) x 85mm (D)
-
+

Details

The OH55F is a 55 inch HD display designed to be used in outdoor areas for 24/7 usage. The slim screen at just 85mm is certified IK10 to resist vandalism, the highest level of resistance offered in designated European strength tests for infrastructure used in the public realm. Protection from dust and liquid ingress is rated at IP56, and it has a wide operating temperature of between -30℃ ~ 50℃, giving the unit the ability to resist all but the most extreme weather conditions. Furthermore, a brightness of 2500 NITS with anti-reflective technology makes the screen viewable in bright sunlight. The display has an internal processor, powering Samsungs Magicinfo S4, SSSP4.0 media player for content management, or can be connected to inputs via 2 x HDMI, 1 x HDCP 2.2 or USB. External control can be done through 1 x RS232C and 1 x RJ45.

Ordering Info

  • OH55F – 55″ High Bright Outdoor Display 24/7 Usage (2500cd/m2)

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  • Diagonal Size: 55″
  • Resolution: 1920*1080 (Full HD)
  • Pixel Pitch(mm): 0.63 x 0.63
  • Active Display Area(mm): 1209.60mm(H) x 680.40mm(V)
  • Brightness(Typ.): 2500 nit
  • Contrast Ratio: 4000:1
  • Viewing Angle(H/V): 178/178
  • Display Colors: 16.7M
  • Video: 2 x HDMI 1.4
  • HDCP: 1 x HDCP 2.2
  • USB: 1 x USB 2.0
  • AC 100 – 240 V~ (+/- 10 %), 50/60 Hz
  • Weight: 46.1kg
  • Mounting: 1186 x 560 (Basic) 1200 x 400 (VESA Bracket Option)
  • Operating Temp: -30.0  ℃  ~   50.0   ℃
  • Processor: Cortex-A12 1.3GHz Quad Core
  • Memory: 2.5GB 3 channel 96bit DDR3-933 (1866MHz)
  • Storage: 8GB (3.75GB Occupied by O/S, 4.25GB Available)
  • OS: Tizen 2.4 (VDLinux)
Screen Size 55"
Aspect Ratio 16:9
Resolution 1920x1080
Brightness 2500nit
Viewing Angle 178/178 (H/V)
I/O HDMI Input, USB
Mounting VESA
Operating Temperature -30° to 50°C
Operating Humidity 10% to 100%
Outdoor Rated Yes
Built In Media Player Yes
CPU ARM
GPU Yes
LAN Yes
OS Tizen
