AEx-821P

Aplex Technology AEx-821P 21.5″ Stainless Steel PPC Class 1/Dive 2/Atex Zone 2

AEx-821P

  • Brand: Aplex Technology
  • Intel Celeron Processor N2930 CPU
  • Class 1 Division 2 & ATEX Zone 2 & IECEx Zone 2 Certified
  • Stainless Steel Housing
  • Wide operating temperature -20°C to +60°C
  • Size: 571mm (W) x 362mm (H) x 75.1mm (D)

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

-
+

Details

The Aplex Technology AEx-821P is a 21.5 inch stainless steel panel PC, rated to IP66; and certified class 1 division 2 and ATEX Zone 2 for hazardous locations. Powered by the Intel Celeron N2930 processor, this hardy touchscreen PC is the perfect choice for environments subject to potential explosives. I/O on the panel pc includes 2 x USB, 1 x COM, 2 x LAN and 1 x VGA, all of which along with the DC power (9-36V wide power input,) are protected by M12 connectors. The 21.5 inch projected capacitive touch TFT-LCD screen has a resolution of 1920 x 1080 and has a brightness of 300 NITS.

Ordering Info

  • AEx-821P – Class 1/Div 2/Atex Zone 2 21.5″ Stainless Steel Panel PC Intel Celeron N2930 CPU

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

CPU:  Intel Celeron Processor N2930
System Chipset: SoC
Memory: 4GB DDR3L on board, 8GB for Option
USB: 1 x M12 8-pin for 2 x USB 2.0 with waterproof cover and chain
Serial / Parallel: 1 x M12 8-pin for COM1, RS-232/422/485, default RS-232, with waterproof cover and chain
LAN: 2 x M12 8-pin for LAN with waterproof cover and chain
Graphics: 1 x M12 8-pin for VGA with waterproof cover and chain
Power: 1 x M12 3-pin for DC power connector with waterproof cover and chain
Storage: 1 x 2.5” HDD or SSD space, 1 x mSATA space, 1 x internal SD card slot
Expansion Slot:  1 x Mini-PCIe (full size)
Display Type: 21.5” TFT-LCD
Luminance (cd/m2): 300
View Angle: 178(H) /178(V)
Contrast: 5000:01:00
Backlight Lifetime: 50,000 hrs
Touch: Projected Capacitive Touch
Interface: USB
Light Transmission(%):  90%
Power Input: DC 9~36V
Power Consumption:  24W
Construction:  316 stainless steel chassis
Mounting: VESA mount 100 x 100, Panel mount (option)
IP Rating Total: IP66
Dimensions: 571 x 362 x 75.1 mm
Net Weight: 13.3 kg
Operating Temperature:  -20~60°C
Storage Temperature:  -30~70°C
Storage Humidity:  10 to 90% @ 40°C, non- condensing
Safety: CSA Std. C22.2 No213-1987
Certificate: CE / FCC Class A, ATEX Zone2 Ex nA ic IIC T4 Gc, Class I, Division2, Group ABCD T4, ANSI/ISA 12.12.01-2013
Touch Technology Projected Capacitive
Ingress Protection IP66
Stainless Steel Yes
Brightness 300nit, Standard
Resolution 1920x1080, FHD
GPU Integrated GPU
Memory Capacity Up to 4GB, Up to 8GB
Cooling Type Fanless, Yes
Serial Ports (COM) 1 Port, RS-232/422/485
USB Ports 2 Ports, 2 Ports, USB 2.0
Ethernet Ports (LAN) 2 Ports, 2 Ports
Storage Type 1, 1x SD Card, 1, 2.5", 3, mSATA, SDCARD
Expansion Type 1, Any Expansion Type, Mini PCI Express
Input Voltage 9-36 VDC
Mounting Options Panel-mount, VESA-mount
Operating Temperature -20°C to 60°C, Wide
Certifications CE/FCC
OS Support Windows 10, Windows 10 IoT, Windows 10 Pro, Windows 7, Windows 8.1
