ViTAM-821BR

Aplex Technology ViTAM-821BR 21.5″ 10th Gen Intel Celeron IP66/IP69K Stainless Steel Panel PC with 250nit Brightness and Resistive Touch

ViTAM-821BR

  • 21.5″ New Generation Stainless Steel Panel PC
  • Intel Celeron J6412 2.0GHz Onboard Processor
  • True Flat Front Bezel Design and Grade 304 Stainless Steel Enclosure (Grade 316 for option)
  • IP66/IP69K Rated with M12 Connectors
  • Support Resistive Touch and Projected Capacitive Touch
  • Touch on/off Button on the Side Edge for Hygienic Cleaning
  • Support Ergonomic Versatile Mounting: Yoke Mounting / Space-saving VESA 100 x 100 mm Mounting

Choose ViTAM-821 Model:

-
+

Details

The Aplex Technology ViTAM-821BR 21.5" 10th Gen Intel Celeron IP66/IP69K Stainless Steel Panel PC with 250nit Brightness and Resistive Touch (PCAP Touch is available). This Panel PC has 10th Gen Intel Celeron J6412 Processor, alongside a True Flat Front Bezel and Grade 304 Stainless Steel Enclosure (Grade 316 is optional).

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Touch Technology Resistive
Ingress Protection IP66, IP69K
Stainless Steel Yes
Brightness 250nit, Standard
Resolution 1920x1080, FHD
GPU Integrated GPU
Memory Capacity Up to 32GB
Serial Ports (COM) 1 Port, 2 Ports, 2 Ports, RS-232/422/485
USB Ports 1 Port, 1 Port, 3 Ports, 4 Ports, USB 2.0, USB 3.0
Ethernet Ports (LAN) 1x 1G, 2 Ports, 2 Ports
Power Over Ethernet (PoE) PoE Ports
Wireless Wi-Fi
CAN Bus Yes
Storage Type 1, 1, 2, 2.5", M.2 SATA
Expansion Type 1x M.2, Any Expansion Type, M.2
Input Voltage 9-36 VDC
Mounting Options VESA-mount, Yoke-mount
Operating Temperature 0°C to 50°C, Standard
Certifications CE/FCC
OS Support Windows 10, Windows 10 IoT, Windows 10 Pro

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

Aplex Technology: Warranty and Service Information

Founded in 2011, Assured Systems are a trusted supplier of Apex Technology, offering comprehensive 2 year warranties on all Apex Technology products supplied in the EMEA. Warranty extensions are also available upon request.
