PM3705-WX45C0

37″ Widescreen Panel Mount Touchscreen Monitor (1366×768)

End of Life

The PM3705-WX45C0 from manufacturer Winsonic is a 37" front widescreen panel mount LCD monitor. With its sleek mechanical design it provides flexible product configuration and easy maintenance. The PM3705-WX45C0 is CCFL Backlit and comes available with auto-brightness sensor. The product is available with optional touchscreen and a variety of video inputs, including a VGA connector with optional AV, SV and AV-Looping.

  • Brand: Winsonic
  • 37 inch LED backlit screen
  • 1366 x 768 resolution
  • 450 NITS brightness
  • Resistive, Capacitive, SAW or Infrared touch options
  • Variety of video inputs
  • Size: 1010mm (W) x 640mm (H) x 124mm (D)

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

-
+

Details

The PM3705-WX45C0 from manufacturer Winsonic is a 37" front widescreen panel mount LCD monitor. With its sleek mechanical design it provides flexible product configuration and easy maintenance. The PM3705-WX45C0 is CCFL Backlit and comes available with auto-brightness sensor. The product is available with Resistive, Capacitive, SAW or Infrared touch options and a variety of video inputs, including a VGA connector with optional AV, SV and AV-Looping.

Ordering Info

  • PM3705-WX45C0: 37″ Widescreen Panel Mount Touchscreen Monitor (1366×768)

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  • Viewable: Image Size: Wide / 37″
  • Resolution: 1366×768
  • Aspect Ratio: 16:9
  • Brightness: 450cd/m
  • Contrast: 2500:1
  • Viewing Angle: H (-89 +89), V (-89 +89)
  • Bezel: Powder Coated Steel
  • Backlight: CCFL
  • VGA: 1 x (15 Pin Female D-Sub)
  • Video Inputs: VGA
  • Touchscreen: Resistive, Capacitive, SAW or Infrared touch options
  • Power: Auto-Sensing, AC 90 to 260v, 50/60 Hz
Screen Size 31" to 40", 37"
