GOT3187W-881-PCT

Axiomtek GOT3187W-881-PCT 18.5″ Multi Touch Panel PC, Intel 4th Gen Core CPUs

End of Life

  • Brand: Axiomtek
  • Intel Celeron J1900 Quad Core 2.42 GHz CPU
  • 1366 x 768 resolution
  • 300 NITS brightness
  • Projected capacitive touch technology
  • Size: 460 mm (W) x 89.5 mm (D) x 285 mm (H)

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

-
+

Details

The GOT3187W-881-PCT is an 18.5” multi-touch Panel PC designed for mission critical applications.  The system is based around Intel’s powerful 4th generation Core family of processors.  The GOT3187W-881-PCT features an aluminium front bezel with a multi-touch projective capacitive touch sensor overlaid within a glass substrate.  The system design is fanless and offers a multitude of I/O including two serial ports, four USB ports and two LAN.

Ordering Info

  • GOT3187W-881-PCT-NP: 18.5″ WXGA TFT Fanless PCAP multi-touch panel computer support Intel LGA1150 socket with 150W adapter

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  • Bezel: Aluminium IP65
  • Display Size: 18.5″ LCD
  • Resolution: 1366 x 768
  • Brightness: 300 NITS
  • Touchscreen: Projective Capacitive
  • CPU: Fanless design supports LGA1150 Socket 4th Generation Intel Core i7/i5/i3/Celeron processors
  • Memory: 1 x 204-pin SO-DIMM DDR3L up to 8 GB
  • Graphics: Integrated Intel HD4000/4600 Graphics
  • Audio: Line outSerial: 2 x RS-232/422/485
  • USB: 2 x USB 2.0 & 2 x USB 3.0
  • Ethernet: 2 x 10/100/1000Mbps
  • Storage: 1 x 2.5” SATA; 1 x mSATA or CFast
  • Expansion: 2 x Mini-PCIe slots
  • Operating Temperature: 0°C ~ +40°C
  • Power Input: 9~36V DC (power adaptor available for AC power)
  • Mounting: IP65 Panel Mount or VESA mount
  • Compliance: CE
Touch Technology Projected Capacitive
Ingress Protection IP65
Brightness 300nit, Standard
Resolution 1366x768, Special/Other
GPU Integrated GPU
Memory Capacity Up to 8GB
Cooling Type Fanless, Yes
Serial Ports (COM) 2 Ports, 2 Ports, RS-232/422/485
USB Ports 2 Ports, 2 Ports, 4 Ports, USB 2.0, USB 3.0
Ethernet Ports (LAN) 2 Ports, 2 Ports
Wireless Cellular, Wi-Fi
Audio Yes
Video Ports 1x HDMI
Storage Type 1, 1, 1, 2, 2.5", CFast, mSATA
Expansion Type 2, 2, Any Expansion Type, Mini PCI Express
Input Voltage 19 VDC
Mounting Options Desktop-stand, Panel-mount, VESA-mount, Wall-mount
Operating Temperature 0°C to 40°C, Standard
Certifications CE/FCC
OS Support Windows 7, Windows 8
