PM1545

15.4″ Widescreen Panel Mount LCD Monitor (1280×800)

PM1545

The PM1545 from manufacturer Winsonic is a 15.4" front widescreen panel mount LCD monitor. With its sleek mechanical design it provides flexible product configuration and easy maintenance. The PM1545 is CCFL Backlit and comes available with auto-brightness sensor that offers application in day and night. The product is available with optional touchscreen and a variety of video inputs, including a VGA connector with optional AV, SV and AV-Looping.

  • Brand: Winsonic
  • 300 NITS
  • Optional touchscreen
  • 1280 x 800 resolution
  • Size: 450mm (W) x 320mm (H) x 64mm (D)
-
+

Details

The PM1545 from manufacturer Winsonic is a 15.4" front widescreen panel mount LCD monitor. With its sleek mechanical design it provides flexible product configuration and easy maintenance. The PM1545 is CCFL Backlit and comes available with auto-brightness sensor that offers application in day and night. The product is available with optional touchscreen and a variety of video inputs, including a VGA connector with optional AV, SV and AV-Looping.

Ordering Info

  • PM1545: 15.4″ Widescreen Panel Mount LCD Monitor (1280×800)

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  • Viewable Image Size: Wide / 15.4″
  • Resolution: 1280×800
  • Aspect Ratio: 16:10
  • Brightness: 300cd/m
  • Contrast: 400:1
  • Viewing Angle: H (-45 +45), V (-45 +20)
  • Bezel: Powder Coated Steel
  • Backlight: CCFL
  • VGA: 1 x (15 Pin Female D-Sub)
  • Video Inputs: VGA
  • Touchscreen: Optional
  • Power: Auto-Sensing, AC 90 to 260v, 50/60 Hz
Screen Size 11" to 20", 15.4"
