FR SC410N4 6G-SDI
YUAN SC410N4 6G-SDI 4CH 4K30 6G-SDI PCIe Capture Card
SC410N4 6G-SDI
Available
SC410N4 6G-SDI
Boards & Modules, PCIe Capture Cards, Video Capture Cards and Encoders, YUAN, YUAN Capture Cards, YUAN PCIe Capture Cards
Specification
| Main | |
| Max. Input Resolution | 3840×2160p@30/25fps |
| Video Input | 4×6G-SDI |
| Dimension | 123.79×91.5 ( mm ) |
| PCIe Full Height | |
| Interface | PCIe×4 ( Gen2 ) |
| Feature | Multi Instances |
| Multi Devices | |
| Video | |
| Video Input Detail | 6G-SDI |
| Video Output | N/A |
| Color Format | Capture/Preview : |
| 4:4:4 8Bit RGB24 | |
| 4:4:4 8Bit RGB32 | |
| 4:2:2 8Bit YUY2 | |
| 4:2:0 8Bit YV12, NV12 | |
| Build-in Hardware Encode | N/A |
| Video Processing | Video, Audio and VANC Capture |
| Video Cropping and Scaling | |
| Auto Signal Detection | |
| Deinterlace Engine | |
| Multi Instances | |
| Video Resolutions | 6G-SDI : |
| 3840×2160p@30/25fps | |
| 3G-SDI : | |
| 1920×1080p@60/50fps | |
| HD-SDI : | |
| 1920×1080p@30/25/24fps | |
| 1920×1080i@60/50fps | |
| 1280×720p@60/50fps | |
| SD-SDI : | |
| 720×480i@60fps | |
| 720×576i@50fps | |
| Audio | |
| Audio Input | 4×Stereo Embedded Audio |
| Audio Format | Stereo / 16-bit / 32000 ~ 48000Hz |
| Misc | |
| GPIO | 16 |
| WatchDog | N/A |
| Software | |
| Supported Software Applications | vMix |
| OBS | |
| ZOOM | |
| Skype | |
| Teams | |
| Discord | |
| Slack | |
| Cisco Webex | |
| GoToMeeting | |
| ※DirectShow/V4L2 Compatable Software Supported | |
| SDK | Windows and Linux SDK |
| OS Support | Windows 7/Windows 8/Windows 8.1/Windows 10 |
| Linux 4.8 or Higher ( 32-bit and 64-bit ) | |
| Linux ARM | |
| nVIDIA Jetson TX2, NANO, AGX Xavier, Xavier NX | |
