Antaira LMP-0702G-SFP-bt-24-T-V2 7-Port 90W Managed Ethernet Switch (-40°~75°C)
Antaira LMP-0702G-SFP-bt-24-T-V2 7-Port 90W Managed Ethernet Switch (-40°~75°C)
LMP-0702G-SFP-bt-24-T-V2 Price: $POA
- Supports 4*10/100/1000Tx IEEE 802.3at/af/bt Compliant with 90W/Port, 1*10/100/1000Tx RJ45 Port, and 2*100/1000 SFP Slots
- Network Redundancy Support: RSTP/MSTP, and G.8032 ERPS v1/v2 (Recovery Time <50ms)
- Configuration: Web Console, Telnet, CLI Command
- Supports IGMP v1/v2/v3, up to 1024 Groups
- Supports QoS (IEEE802.1p) and CoS/ToS
- Supports IEEE802.1Q VLAN, SNMP v1/v2c
- Power Input: 12~55VDC in 6-Pin Terminal Block
- Reverse Polarity Protection
- IP30 Protection
- DIN-Rail or Wall Mountable
- Operating Temperature Range – EoT: -40° to 75°C
- 5-Year Warranty
For more information please click “Add to Inquiry”. Alternatively you can contact our US sales team on +1 347 719 4508.
LMP-0702G-SFP-bt-24-T-V2
Assured Systems USA
Antaira, Industrial Ethernet/Wireless, Industrial PoE++ Devices
USD
Details
Antaira Technologies’ LMP-0702G-bt-SFP-24-T-V2 is a 7-port industrial Gigabit PoE+ managed Ethernet switch embedded with 4*10/100/1000Tx Ethernet ports that support IEEE802.3at/af/bt for a maximum of 90W/port, 1*10/100/1000Tx Gigabit Ethernet port, and 2*100/1000 dual rate SFP slots for fiber connection. The LMP-0702G-SFP-bt-24-T-V2 is a fully manageable Light Layer 3 Ethernet switch that is pre-loaded with a user-friendly web management console design. It supports the ring network redundancy function using the market’s open standard ITU-T G.8032 Ethernet Ring Protection Switch (ERPS) protocol that has a <50ms network recovery time. The advanced network filtering and security functions, such as IGMP, VLAN, QoS, SNMP, RMON, Modbus TCP, and 802.1X/HTTPS/SSH/SSL increase determinism and improve network management for remote SCADA systems or control networks. The LMP-0702G-SFP-bt-24-T-V2 is IP30 rated and DIN-rail mountable. It also provides high EFT and ESD protection for industrial networking applications, such as power/utility, water wastewater, oil/gas/mining, factory automation, security surveillance, ITS and any other outdoor or harsh environment.
Downloads
Assured Systems Datasheet (PDF)
A PDF edition of this page with supporting manufacturer datasheets
System Integration
Please ask about how we can configure your solution
Global Operations
We ship and support products via offices globally
Full Warranty
Industry leading warranties on all solutions as standard
Technical Support
Experienced engineers are on hand to support your project
Can't Find What You Want?
Specification
| Ambient Relative Humidity | 5% to 95%, (non-condensing) |
| Certifications | FCC, CE |
| Configuration | Http, Https, Telnet, SSH, CLI, TFTP, SNMP v3 |
| Dimensions | 54 x 142 x 99 mm (W x H x D) |
| EMI | FCC Part 15 Subpart B Class A,CE EN55032/EN61000-6-4 Class A |
| EMS | CE EN55035/EN61000-6-2 Class A,IEC61000-4-2,3,4,5,6,8 |
| Ethernet Port | 5*10/100/1000Base-TX (90W/Port for Port 1~4 only), auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection |
| Flow Control | IEEE 802.3x flow control, back pressure flow control |
| Free Fall | IEC60068-2-32 |
| Green | RoHS Compliant |
| Housing | Metal, IP30 protection |
| IGMP Group | 1024 |
| Input Voltage | 12~55VDC Redundant Input(53~55VDC power input for BT PoE PSE) |
| Jumbo Frame | 9.6Kbytes |
| L2 Switching | Port/MAC/Protocol/IP Subnet-based VLAN, VLAN trunking, GARP/GVRP, Loop Guard, Link Aggregation static/LACP, BPDU guard, Error disable recovery, IGMP v1/v2/v3 snooping, MLD snooping, IGMP filtering, IPMC throttling / filtering leave proxy, DHCP snooping, ARP, MEP, G.8032 v1/v2 |
| L3 Switching | DHCP option82, static routes |
| LED Indicators | System: Power 1, Power 2, Master, Ring, Status, and PoE LoadEthernet Ports: Speed/Link/ActivePoE: On-connected to PD devicesSFP: Link/Active |
| MAC Table Size | 8K |
| Memory Buffer | 4Mbits |
| Mounting | DIN-Rail mounting, Wall mounting |
| Network Cable | 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable EIA/TIA-568 100-ohm (100m)100Base-TX: 2-pair UTP/STP Cat. 5 cable EIA/TIA-568 100-ohm (100m)1000Base-T: 4-pair UTP/STP Cat.5/5E cable; EIA/TIA-568 100-ohm (100m) |
| Network Redundancy | STP/RSTP/MSTP, port trunk with LACP, ERPS v1/v2 (<50ms) |
| Operating Temperature | -40°C to 75°C |
| Overload Current Protection | Present |
| Poe Pin Assignment | V-, V-, V+, V+ for pin 1, 2, 3, 6V+, V+, V-, V- for pin 4, 5, 7, 8*Support Modes: Mode A, Mode B, 4-Pair Mode |
| PoE Power Budget | 90W @12VDC180W @24VDC240W @36~55VDC |
| Power Connection | 1 removable 6-contact terminal block |
| Power Saving | ActiPHY, PerfectReach, IEEE 802.3az EEE power management |
| Priority Queues | 8 |
| Processing Type | Store and Forward |
| Protocols | IPv4/IPv6, SNMP v1/v2c/v3, LLDP, LLDP-MED, HTTP, HTTPS, SSHv2 telnet, DHCP client, DHCPv6 client, DHCP server, Port Mirror, DNS client/proxy, IP based Access Filter, ICMPv6, syslog, Time Zone / Daylight Saving, NTP client, RMON, sFlow, Loop detection, Console Port, Power Lost Warning, Relay Trigger |
| QoS | 802.1p Queueing, Input priority mapping, Storm control for Unicast/Multicast/Broadcast, Port/Queue/ACL policer, Port egress shaper, Queue egress shaper, DiffServ (DSCP), Tag remarking, Scheduler mode |
| Relay Contact | 24VDC, 1A resistive |
| Reverse Polarity Protection | Present |
| RS232 Serial Console | 1*RS232 in RJ45 |
| SFP Port | 2*100/1000 SFP Slots |
| Shock | IEC60068-2-27 |
| Storage Temperature | -40°C to 85°C |
| Switching Architecture | Back-Plane (Switching Fabric): 14Gbps |
| System / Diagnostics | Dual Image Protection, PING, PING6 |
| System Power Consumption | 10.8W |
| Transfer Rate | 14,880pps for Ethernet Port148,800pps for Fast Ethernet Port1,488,000pps for Gigabit Ethernet Port |
| Vibration | IEC60068-2-6 |
| VLAN Groups | 4095 |
| Warranty | 5 Years |
| Weight | Unit: 2.35 lbsShipping: 3.06 lbs |
