POC-451VTC ULTRA COMPACT EMBEDDED PC

POC-451VTC ULTRA COMPACT EMBEDDED PC

Intel Atom x6425E 2.0GHz Ultra Compact Embedded PC with 1x 2.5Gigabit Ethernet, 2x 2.5Gigabit PoE+ ports, up to 4x COM and E-Mark certification

  • Intel Atom x6425E quad-core processor
  • Rugged -25°C to 70°C fanless operation
  • 2x 2.5GbE PoE+ ports and 1x 2.5GbE port
  • 1x M.2 2242/ 3052 B key for 4G/5G module
  • 2x M.2 2230 E key for WIFI and edge TPU module
  • Conduction-cooled heatsink for M.2/ mPCIe modules
  • Dual M.2 2280 M key for SATA SSD
  • 8~35V DC input with built-in ignition power control

For more information please click “Add to Inquiry”. Alternatively you can contact our US sales team on +1 347 719 4508.

abc

abc

ABC

ABC

ABC

ABC

Details

The Neousys POC-451VTC is an ultra-compact in-vehicle computer with E-Mark certificate for in-vehicle applications, such as a mobile gateway, mobile surveillance and passenger information system. Leveraging the Intel Elkhart Lake Atom x6425E CPU, it delivers 1.8x the CPU and 2x the GPU performance improvement when compared to the previous generation.

The POC-451VTC provides multiple M.2 and mPCIe slots to install 4G/5G, WiFi5/6, CAN bus, and edge TPU modules for modern in-vehicle applications. It can therefore extend WiFi and broadband wireless communications as well as provide AI inference functionality inside a compact footprint. To cope with the high-performance modules, POC-451VTC has a dedicated conduction-cooled heat spreader to dissipate the heat generated by M.2/mPCIe modules to maintain optimal system performance in high-temperature environments.

Connectivity-wise, POC-451VTC offers three 2.5GBASE-T Ethernet ports with PoE+ capability for powering PoE PD devices, such as IP and GigE cameras. The ports are backward-compatible with 1000/100 Mbps Ethernet to work with most existing Ethernet devices. The system also provides isolated DIO for sensor/ actuator control and 8V-35V wide range DC input with ignition power control for in-vehicle deployment.

With a significant performance boost, 2.5G PoE+ ports, superior thermal reliability for communication and inference, POC-451VTC is an AI-capable, mobile gateway solution that opens the door to more possibilities for in-vehicle applications.
