Diamond Systems JETBOX-FLOYD NVIDIA Jetson Nano/Xavier NX AI Edge Computer

Name: Diamond Systems JETBOX-FLOYD NVIDIA Jetson Nano/Xavier NX AI Edge Computer
SKU: JETBOX-FLOYD
Availability: InStock

Diamond Systems

Diamond Systems JETBOX-FLOYD NVIDIA Jetson Nano/Xavier NX AI Edge Computer

JETBOX-FLOYD

Complete system with Jetson Nano or NX module and Linux OS installed
1x or 2x Gigabit Ethernet ports
Optional PoE+ support (with external power source)
2x HDMI 2.0a/b ports
1x USB 3.0 port with type A connector
2x USB 2.0 ports with type A connector; 1x port can serve as OTG
8x GPIO with 3.3V logic levels
2x serial ports with RS-232/422/485 (depending on model)
3x dual/quad lane MIPI/CSI camera ports
1x CAN port (NX module only)
1x Mini PCIe socket with PCIe and USB support
1x M.2 2280 PCIe x1 or x4 NVME socket
Input voltage 7-28VDC; 12VDC universal AC adapter included
Operating temperature -25 to +80C
Dimensions: 175mmW x 91mmD x 53mmH / 6.9″W x 3.6″D x 2.1″H

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

I require customisation *
Please share some background information on your project to help us ensure we’re proposing the best solution *
What processing level is required? *
How much RAM do you require? *
How much storage is required? *
What is the project timeline? *
What operating system would you like to use? *
Do you need any Wi-Fi or Cellular? *
- Wi-Fi
- Cellular
Do you need wide-temperature components? *
- Yes
- No
Do you need a mounting kit? *
Do you need an AC-DC power supply? *
Do you need any additional expansion modules? *

Product Code: JETBOX-FLOYD

Categories: Diamond Systems, Edge AI & GPU Computers, Embedded NVIDIA Jetson Systems, NVIDIA Jetson Nano Systems, NVIDIA Jetson Systems, NVIDIA Jetson Xavier NX Systems

Range: Diamond Systems

Details

The Diamond Systems JETBOX-FLOYD is a compact Nvidia Jetson AI computing platform ready to deploy. It includes the Jetson Nano or NX module installed on our FLOYD carrier board with a Linux OS installed and preconfigured to support all the I/O on Floyd.

The system is available multiple standard configurations to meet a range of customer needs. The 01 full-feature models feature dual Ethernet ports with PoE support using an external power injector, two multi-protocol serial ports, dual HDMI displays, and a PCIe / USB minicard socket. The 02 low-cost models have fewer baseline I/O features but offer a faster-performance PCIe x4 NVME M.2 socket. Both models will support one channel of CAN 2.0B with the Xavier NX module installed.

Jetbox-Floyd features multiple expansion sockets for additional I/O and storage capacity to meet a wide range of application needs. Dual SMA antenna cutouts support the installation of wifi and cellular modem modules for network connectivity. The enclosure is DIN rail mountable or can be used in a “table top” scenario.

The system is compatible with both 12V and 24V DC power supplies. A 12VDC universal AC adapter is included with the system.

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Specification

Feature	JB-FLD-NAO-01	JB-FLD-NAO	JB-FLD-XNX-01	JB-FLD-XNX-02
Jetson module	Nano	Nano	Xavier NX	Xavier NX
Gigabit Ethernet	2	1	2	1
PoE	Both ports	No	Both ports	No
HDMI	2	1	2	1
Camera CSI 4-lane	3	3	3	3
USB 3.0	1	1	1	1
USB 2.0	2	2	2	2
M.2 2280 socket	PCIe x1	PCIe x4	PCIe x1	PCIe x4
Minicard socket	Full size PCIe + USB	No	Full size PCIe + USB	No
SD card	Yes	Yes	Yes	Yes
GPIO 3.3V	8	8	8	8
Serial	2x RS-232/422/485	1x RS-232 1x RS-232/485	2x RS-232/422/485	1x RS-232 1x RS-232/485
CAN 2.0	No	No	1	1

Processor Type	NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX
Serial Ports (COM)	1x RS-232, 1x RS-232/422/485, 2x RS-232/422/485
USB Ports	1x USB 3.0, 2x USB 2.0
Ethernet Ports (LAN)	1x 1G, 2x 1G
Power Over Ethernet (PoE)	PoE Ports
CAN Bus	Yes
Video Ports	1x HDMI, 2x HDMI
Storage Type	1x M.2 PCIe, 1x SDCARD
Expansion Type	1x M.2, 1x PCI Express
Input Voltage	12 VDC, 7-28 VDC
Operating Temperature	-25°C to 80°C
OS Support	Linux
