Aplex Technology ViTAM-116 15.6″ TFT-LCD IP66/IP69K Stainless Steel Display

Aplex Technology ViTAM-116 15.6″ TFT-LCD IP66/IP69K Stainless Steel Display


15.6" TFT-LCD IP66/IP69K Waterproof Stainless Steel Monitor with Optional High Bright Display, PCAP Touch Screen and HDMI Input (1366×768)

  • 15.6″ TFT-LCD.
  • True Flat Front Bezel and Grade 304 Stainless Steel Enclosure (Grade 316 for Option).
  • IP66/IP69K Rated with M12 Connectors.
  • Touch on/off Button on the Side Edge for Hygienic Cleaning.
  • Support Ergonomic Versatile Mounting: Yoke Mounting / Space-saving VESA 75 x 75 mm Mounting


The Aplex Technology ViTAM-116 is a 15.6″ TFT-LCD New Generation Display with a true flat front bezel design and grade 304 stainless steel enclosure. This Stainless Steel Display comes with Projective Capacitive Touch, Resistive Touch, Anti-Reflection Coating Glass and High Brightness options.

Ordering Info

ViTAM116P P-CAP Touch
ViTAM116R Resitive Touch
ViTAM116G Anti-Reflection Coating Glass
ViTAM116PH P-CAP Touch/High Brightness
ViTAM116RH Resitive Touch/High Brightness
ViTAM116GH Anti-Reflection Coating Glass/High Brightness


Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?


VGA 1 x M12 VGA by 12-pin cable with waterproof cap
HDMI 1 x waterproof HDMI with with waterproof cap
OSD Control Membrane  OSD on the rear side
Others 1 x M12 for USB touch with waterproof cap
Power 1 x Power input, 1 x Touch on/off button on the side
LCD Size 15.6″ TFT-LCD
Max. resolution 1366 x 768
Max. color 16.7M
Luminance(cd/m²) 300
Viewangle(H°/V°) 160/160
Contrast 800:1
Backlight lifetime(hrs) 50000
Interface  USB
Light transmission(%)  Over 90%
Power input 9~36V DC
Construction Stainless steel enclosure
IP rating IP66/IP69K
Mounting VESA 75 x 75, Yoke mount
Dimension(mm) 440 x 290 x 55
Net weight(Kgs) 6.5 Kg
Operating temperature(°C) 0~50°C (-20~60°C option)
Storage temperature(°C) -30~70°C
Storage humidity 10 to 90% @ 40°C, non- condensing
Certification CE / FCC CLASS A
Screen Size 15.6"
